Characteristics
- Corrosion-resistant
- Protected against strong vibrations and shocks
- Protected against electromagnetic interference
- High-quality versions such as marine bronze (version B) or Aluminium alloy, surface zinc–tin coated and/or black anodized, screen termination system electrically conductive (version J)
Technical Information
Documents
Videos
3D models
Product overview
VG95328
compact & robust circular connector, bayonet locking, signal and power transmission
- up to 61 contacts per connector
- max. 40A current per contact
- AWG crimp contacts, solder contacts or wire wrap contacts
VG96912
compact & robust circular connector, bayonet locking, signal and data transmission
- up to 128 contacts per connector
- up to max. 23A current per contact
- Data connector (10Gbit/s)
- Contact protection & interface seal
VG95234
Robust circular connector, reverse bayonet locking, signal and power transmission
- up to 61 contacts per connector
- max. 245A current per contact
- large variety of types
VG95319-1016 A, B, C, G, H, N
Robust and lightweight circular connector, Tri-Start thread locking, signal, data and power transmission
- up to 187 contacts in one connector
- Suitable high-speed contacts available
- Double flange receptacles
- Bulkhead feedtrough
VG95319-1006/-1007/-1008
Robust and lightweight circular connector, Tri-Start thread locking, signal, data and power transmission
- up to 187 contacts in one connector
- large variety of types
- suitable high-speed contacts available
VG95319-1016 D, E, F
Robster circular connector, Tri-Start thread locking, for MPO connectors
- Suitable for standard MPO connectors / patch cables
- Installation without special tools
VG95319-1016 K,L,M
Modular circular connector, Tri-Start thread locking, signal, data and power transmission
- up to 30 contacts per connector
- Circular connector available with 90° PCB contacts
- diverse fiber optic termination options
VG96929
Robust single-pole circular connector, reverse bayonet locking, high-current power transmission
- single-pole power connector
- max. 950A current per contact
- for cables from 25mm² to 240mm²
VG96944
Robust circular connector, Tri-Start thread locking, secure power transmission
- max. 100A current per contact
- max. 1000V operating voltage
- Pilot Contact (LMFB)
- Grounding contact (FMLB)
- Contact protection - safety for the user
VG96949
Robust circular connector and cable, Tri-Start thread locking, USB 3.0 high-speed data transfer
- Sealed against liquids and dust (IP67)
- Shock and vibration resistant
VG95319-1011
Backshells, EMC, dirt and moisture protection
- Water pressure resistant 1 bar/48 h
- Wide selection of cable diameters
- Different materials and surfaces
VG95319-1015 A
For attaching a shielding braid; EMC protection; strain relief
- Suitable for VG95319-1011 and M85049 backshells
- Stainless steel, passivated
- Temperature range: -46°C to 200°C
VG96513
Modular rectangular connector, rack & panel, cable mounting with locking nut or push-pull locking, signal, data and power transmission
- up to 120 contacts per connector
- max. 125A per contact
- Variety of modules and configuration options
VG95218T031 Type B001
Cable by the meter, CAT7 Ethernet data transmission
- Data transmission in harsh environments
- UV-resistant and halogen-free
- RoHS compliant
VG95319-100, -101, -102
Durable lens circular connector, hermaphroditic thread locking, fiber-optic high-speed data transmission
- 2 or 4 channels
- 3000 mating cycles
- Multimode or singlemode
VG95319-1009
High-speed video or data transmission, 75 Ohm coaxial contacts / fiber optic contacts
- suitable for VG95319 -1006, -1007, -1008, -1016
- Coaxial: Characteristic impedance: 75Ω / Frequency range: 0-3 GHz
- Fiber optic: Insertion loss: 0.45 typical / Back reflection: better than -40dB
VG96940-6
Electrically conductive seals, EMC, dirt and moisture protection
- Frequency range: 15KHz to 4GHz
- Shielding effect up to ≥ 80 dB
- Suitable for a wide range of connector series and shell styles
VG96927-2 / Basic type A-D1 & M-P
Harnesses according to VG96929-2
- for copper cables type A-D1 & optical fibers type M-P
- IPC/WHMA-A-620 approved
- own production at the Saarlouis site
VG96953-13
Grounding metal strip stainless steel (V4A) with low resistance
- for grounding or power distribution
- different widths and lengths available
VG96936-10 | VG96927-9
Metallic braided conductors sold by the meter or assembled with cable lug
- Nominal cross sections available from 1.5mm² to 120mm²
- assembled with cable lugs with 60mm to 450mm length
